YXYSW5
SKYWING
|
|
|
|
High wattage from 120W to 1200W Light efficiency up to 140lm/W, 160lm/W, 180lm/W Single module 120W/150W/200W, up to 6 modules can be combined into 1200W High strength polycarbonate lens, optical lighting distribution: 30°/ 45°/ 60°/ 90°/ 80140°/ 12030*60° Die casting heat sink: Excellent thermal management & Compact structure Embedded cable raceway: Optimize cable layout Racked angle: Allows for precise installation, up to 270° 4mm thickness U shape bracket: High-strength cold-rolled plate designwith integral flanging and bending, light weight, high mechanical strength, Special corrosion treatment to reach the WF2 standard. Integrated breather valve: Balances the internal & external temperature & humidity Tempered glass cover option: To apply in harsh conditions Top brand LED chip and driver, ensure the product quality and lifetime Ingress protection: IP66 waterproof Double surge protection: Driver & extra 10KV SPD |
|
|
|
|
Model Configuration Table:
|
Model No. |
YXYSW5- E200W |
YXYSW5- E400W |
YXYSW5- E600W |
YXYSW5- E800W |
YXYSW5- E1000W |
YXYSW5- E1200W |
||||
|
Power |
200W |
400W |
600W |
800W |
1000W |
1200W |
||||
|
Input Voltage |
AC100-277V;50/60Hz |
|||||||||
|
Lumen EFF |
150LM/W(±5%) |
|||||||||
|
LED Brand |
LUMILEDS 3030/LUMILEDS 5050 |
|||||||||
|
Driver Brand |
MEANWELL/ SOSEN /INVENTRONICS |
|||||||||
|
CCT |
3000K/4000K/5000K/5700K/6500K |
|||||||||
|
CRI |
Ra>80(70,90 Optional) |
|||||||||
|
PF |
0.95 |
|||||||||
|
Beam Angle |
30°/45°/60°/90°/120*40*60°/80*140° |
|||||||||
|
IP Rating |
IP66 |
|||||||||
|
IK Rating |
IK08 |
|||||||||
|
Warranty |
5 Years |
|||||||||
|
Life Span |
50,000Hrs |
|||||||||
|
Working Temperature |
-35℃-+50℃ |
|||||||||
|
Dimmension(mm) |
150*490*140mm |
315*490*155mm |
428*490*155mm |
555*490*155mm |
668*490*155mm |
776*490*155mm |
||||
|
Certifcation |
UL/ETL/CQC/CB/CE/ENEC/SAA/FCC/RoHS |
|||||||||
Case diagram:
